The BJZ100 with their proven reliability and excellent self-priming ability make them ideal for any house or farm water supply system. The Jet and venturi design allows suction lift up to 8m – great for drawing from rivers, dams & ponds, shallow wells and underground tanks. Easy to prime.
TECHNICAL FEATURES:
Max working pressure: 8bar
Max liquid temperature: +60°c
Max suction lift: 8m
MOTOR FEATURES:
TEFC continuous duty motor
Class B Insulation
Ambient temperature: ≤50°C
Internal overload protector
IP55 protection
CONSTRUCTION MATERIALS:
Pump casing, seal plate, pump shaft & Impeller: 304 Stainless Steel
Mechanical seal: Carbon/Ceramic
Diffuser/Venturi: PPO
O Rings: EPDM
Motor mount and casing: Aluminium
Part No. BJZ100
hp 1.0
kW 0.7
Inlet/Outlet 25mm
Phase 1
Voltage 220-240
Amps 5.2
Trevoli BJZ100E With DSK Controller: Powerful Self-Priming Pump for Water Supply Systems
Superior Performance for Residential and Agricultural Applications
The Trevoli BJZ100E with DSK Controller delivers exceptional performance for water supply systems, combining robust construction with industry-leading self-priming capabilities. With its powerful 1.0 hp motor and innovative jet/venturi design, this pump provides reliable water delivery from multiple sources with an impressive 8m suction lift capacity.
Key Technical Specifications
| Feature | Specification |
|---|---|
| Motor Power | 1.0 hp (0.7 kW) |
| Max Working Pressure | 8 bar |
| Suction Lift | 8 meters |
| Port Size | 25mm inlet/outlet |
| Electrical | Single-phase 220-240V |
Premium Construction Features
- 304 Stainless Steel components for corrosion resistance (pump casing, seal plate, shaft & impeller)
- Carbon/Ceramic Mechanical Seal for extended service life
- PPO Diffuser/Venturi for chemical resistance
- EPDM O-Rings for superior sealing
- Aluminum Motor Housing for lightweight durability
Advanced Motor Protection System
The BJZ100E is equipped with multiple protection features:
- TEFC (Totally Enclosed Fan Cooled) motor design
- Class B insulation for heat resistance
- Built-in overload protection
- IP55 rating against dust and water ingress
- Operates in ambient temperatures up to 50°C
Ideal Water Source Applications
This versatile pump excels at drawing water from various sources:
- Surface Water: Rivers, streams, and ponds
- Stored Water: Dams and above-ground tanks
- Underground Sources: Shallow wells and boreholes
- Rainwater Harvesting: Tank collection systems
Why Choose the BJZ100E?
- Powerful Performance: 1.0 hp motor delivers strong water flow
- Easy Operation: Self-priming design simplifies startup
- Durable Construction: Stainless steel components resist corrosion
- Low Maintenance: Quality materials reduce servicing needs
- Energy Efficient: Optimized design minimizes power consumption
For complete technical details, visit the Trevoli BJZ100E product page.
Installation and Maintenance Recommendations
- Install check valves on suction lines to maintain prime
- Ensure all pipe connections are watertight
- Protect from freezing in cold climates
- Inspect seals and bearings annually
- Clean intake screens regularly to maintain flow
The Trevoli BJZ100E with DSK Controller represents an excellent balance of power, reliability, and efficiency for water supply applications. Its robust stainless steel construction and powerful 1.0 hp motor make it particularly suitable for larger residential properties, small farms, and commercial applications requiring dependable water delivery.
