The BJZ150 with their proven reliability and excellent self-priming ability make them ideal for any house or farm water supply system. The Jet and venturi design allows suction lift up to 8m – great for drawing from rivers, dams & ponds, shallow wells and underground tanks. Easy to prime.
TECHNICAL FEATURES:
Max working pressure: 8bar
Max liquid temperature: +60°c
Max suction lift: 8m
MOTOR FEATURES:
TEFC continuous duty motor
Class B Insulation
Ambient temperature: ≤50°C
Internal overload protector
IP55 protection
CONSTRUCTION MATERIALS:
Pump casing, seal plate, pump shaft & Impeller: 304 Stainless Steel
Mechanical seal: Carbon/Ceramic
Diffuser/Venturi: PPO
O Rings: EPDM
Motor mount and casing: Aluminium
Part No.
hp
kW
Inlet/Outlet
Phase
Voltage
Amps
BJZ150
1.3
1.0
25mm
1
220-240
6.2
Trevoli BJZ150E With DSK Controller: High-Performance Self-Priming Water Pump
Industrial-Grade Water Supply Solution for Demanding Applications
The Trevoli BJZ150E with DSK Controller represents the pinnacle of self-priming pump technology, delivering exceptional 1.3hp performance for residential, agricultural, and commercial water supply systems. Engineered with professional-grade components, this pump features an advanced jet and venturi design capable of 8m suction lift – perfect for challenging water sources.
Technical Specifications at a Glance
| Model | BJZ150E |
|---|---|
| Motor Power | 1.3 hp (1.0 kW) |
| Maximum Pressure | 8 bar |
| Suction Capacity | 8 meters vertical lift |
| Port Configuration | 25mm inlet/outlet |
| Electrical Requirements | Single-phase 220-240V, 6.2A |
Premium Construction for Maximum Durability
- All-Stainless Fluid Path: 304 stainless steel pump casing, seal plate, shaft and impeller resist corrosion and abrasion
- Advanced Sealing System: Carbon/ceramic mechanical seal with EPDM O-rings ensures leak-free operation
- Chemical-Resistant Components: PPO diffuser/venturi withstands aggressive water conditions
- Rugged Motor Housing: Lightweight aluminum casing provides optimal heat dissipation
Professional-Grade Protection Features
- TEFC (Totally Enclosed Fan Cooled) motor design for continuous duty operation
- Class B insulation handles elevated temperatures
- Internal overload protector prevents motor damage
- IP55 protection against dust and water ingress
Ideal for These Water Supply Challenges
Agricultural Irrigation
Reliable water delivery for crops and livestock
Rural Property Supply
Consistent pressure for multiple household fixtures
Commercial Water Transfer
High-volume movement between storage tanks
Key Advantages Over Conventional Pumps
- Superior Priming Performance: Maintains prime even after periods of inactivity
- Exceptional Suction Power: Handles vertical lifts that defeat standard centrifugal pumps
- Reduced Maintenance: Premium materials extend service intervals
- Energy Efficient: Optimized impeller design minimizes power consumption
- Quiet Operation: Precision-balanced components reduce vibration and noise
For complete technical documentation, visit the Trevoli BJZ150E product page.
Professional Installation Recommendations
- Mount on vibration-absorbing base for quiet operation
- Install foot valve on suction line to maintain prime
- Use rigid piping for suction lines to prevent collapse
- Consider frost protection for outdoor installations
Maintenance Best Practices
- ✓ Quarterly inspection of mechanical seals
- ✓ Annual bearing lubrication
- ✓ Biannual cleaning of intake screens
- ✓ Immediate attention to any performance changes
The Trevoli BJZ150E with DSK Controller sets the standard for professional water supply systems, combining industrial-grade construction with user-friendly operation. Its 1.3hp motor delivers the power needed for demanding applications while maintaining the efficiency expected from modern pumping technology.
For larger scale requirements, explore our multistage pump solutions, or consult with the water system experts at Pumps and Filters NZ for personalized system design.
